Sun's Assembly Build Process allows you to configure a cartridge and
manifold, or main stage and pilot stage cartridge, and build a
digital assembly in three dimensional space. The resulting output of
this process is the assembly product page, including
configuration-specific images, symbols, product information and CAD
files for download.
The Assembly Build Process can be accessed from either a cartridge or
manifold product page. Only valid choices are allowed.
From a manifold page, you must first choose your cartridge function.
Once you choose your function, click on the BUILD ASSEMBLY button
below the WHERE TO BUY BUTTON. Once clicked, you will be
presented with valid cartridges for your manifold. Select the
cartridge of your choice and follow the instructions at the top of
the page. If your particular combination has been generated before,
the resulting assembly page will be available immediately. If not,
you will be asked to enter your email address. Once the page is
complete, an email will be sent to you including a link to the
assembly product page.
From a cartridge product page, click on BUILD ASSEMBLY and you will
be presented with a listing of compatible manifolds. In the case of
main stage and pilot stage cartridges, you can either build a
cartridge to cartridge assembly or a cartridge to manifold assembly.
Once your choice has been made, follow the instructions at the top
of the page. If your particular combination has been generated
before, the resulting assembly page will be available immediately.
If not, you will be asked to enter your email address. Once the page
is complete, an email will be sent to you including a link to the
assembly product page.
Please note that the Assembly Build Process is an automated process.
It can be utilized at any time. Pages are generated typically within
minutes but delays can occasionally be expected. In the event of a
delay, a team at Sun will work to resolve the issue to ensure you
receive your information as quickly as possible.
